JA 460W Solar Panel

(0 customer reviews)

R1,316.00

  • FREE Delivery in Gauteng (Minimum order 4 Solar Panels)
  • Please contacts us for deliveries outside Gauteng

Availability: Available on backorder

JA Solar

R1,316.00

Availability: Available on backorder

Wishlist
Compare
Add to cart
Buy Now
Category:

The JA Solar 460W mono panel is a high-efficiency module designed for residential and commercial solar systems. The panel has a power output of 465 watts, which means it can generate a large amount of electricity from a relatively small surface area. This makes it a good choice for installations where space is limited. The panel uses monocrystalline solar cells, which are more efficient than polycrystalline cells. This means that it can convert more sunlight into electricity, which translates into higher power output. Overall, the JA Solar 465W mono panel is a high-quality, efficient solar module that can be a good choice for residential and commercial solar installations. However, it’s always important to consult with a professional solar installer to determine the best solar panels for your specific needs and location.

12 Year Product Warrenty
21.3% Maximin Efficiency
0.55% Yearly Degredation



Specifications:

  • Cell: Mono.
  • Weight: 24.7kg±3%.
  • Dimensions: 2112±2mm×1052±2mm×40±1mm.
  • Cable Cross Section Size: 4mm².
  • No. of cells: 144(6×24）.
  • Junction Box: IP68, 3 diodes.
  • Cable Length: (Including Connector) 1200mm (+)/1200m(-)

Electrical Parameters at STC:

  • Max. system voltage: 1000/1500 VDC.
  • Type: JAM60S20-460/MR
  • Rated Maximum Power (Pmax) [W]: 460.
  • Open Circuit Voltage (Voc) [V]: 50.01.
  • Maximum Power Voltage (Vmp) [V]: 42.13
  • Short Circuit Current (Isc) [A]: 11.45.
  • Maximum Power Current (Imp) [A] 10.92.
  • Module Efficiency [%]: 20.7.
  • Power Tolerance: 0~+5W.
  • Temperature Coefficient of Isc(α_Isc): +0.044%/℃.
  • Temperature Coefficient of Voc(β_Voc): -0.272%/℃
  • Temperature Coefficient of Pmax(γ_Pmp): -0.350%/℃
  • STC: Irradiance 1000W/m², cell temperature 25℃, AM1.5G.
  • Short Circuit Voltage (Isc): 11.45 A.
  • Max. series fuse rating: 20 A.
Weight 24 kg
Dimensions 211 × 105 × 3.5 cm
